| Place of Origin: | China |
|---|---|
| Brand Name: | HYPER |
| Certification: | DIN VDE 0623 EN/IEC 60309-2 |
| Model Number: | 1007 |
| Minimum Order Quantity: | 500pcs |
| Packaging Details: | packed by standard paper carton |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100,000pcs / month |
| Name: | Inlet | Type: | Inclination |
|---|---|---|---|
| Current & Voltage: | 32A 400V | Poles: | 4P |
| Protection Grade: | IP67 Water Tight | Earth Position: | 6H |
| Highlight: | industrial power plugs sockets,waterproof plug and socket |
||
4P 32A IP67 Weather-protected Wall Mounted Red Industrial Inlet Inclination Waterproof Plug Socket part no. 1007
Description:
Have you ever thought about ways how your favourite fresh food gets to the table where it is served? How long it travels and what transport condition it needs to have to stay fresh?
The goods, which need specific stable temperature, are mostly transported in refrigerator ships and transport containers. Thanks to Industrial plugs and sockets they are connected to power supply, also in a harbour, which enable the temperature control. To meet strict demands of this application, ABB offers watertight (IP67) reefer plugs and sockets, powered with 32 A, 440 V 50/60 Hz, 3P+E with earth sleeve in 3 o’clock position, according to IEC/EN 60309-2. The wide range of ABB contains plugs, connectors, outlets, inlets as well as interlocked socket outlets and socket outlets with residual current devices and miniature circuit breakers. These products are corrosion, impact and UV resistant.
Part no. 1007
Technique Parameter:
| Current | Poles | 110V 50a.60Hz |
230V 50a.60Hz |
400V 50a.60Hz |
500V 50a.60Hz |
>50-500V 100-300Hz |
>50-500V a.300-500Hz |
Package Unit | Weight |
| 3P 4P 5P 4h 4h 4h |
3P 4P 5P 6h 9h 9h |
3P 4P 5P 9h 6h 6h |
3P 4P 5P 7h 7h 7h |
3P 4P 5P 10h 10h 10h |
3P 4P 5P 2h 2h 2h |
PCS/BOX | G/PC | ||
| 32A | 3 | 3437 | 1006 | 3457 | 10 | 234 | |||
| 4 | 3467 | 3477 | 1007 | 3497 | 10 | 253 | |||
| 5 | 3527 | 3537 | 1008 | 23867 | 10 | 292 |
| Current | Poles | a | b | c | d | e | f | g | h | m | m* | ||||
| 32A | 3 | 90.2 | 79 | 98.5 | 120.7 | 148.4 | 162.8 | 5.5 | 5 | 32 | can use 1PC M32 CABLE GLAND | ||||
| 4 | 90.2 | 79 | 98.5 | 120.7 | 148.4 | 162.8 | 5.5 | 5 | 32 | ||||||
| 5 | 90.2 | 79 | 98.5 | 120.7 | 148.4 | 161.8 | 5.5 | 5 | 32 | ||||||
| Conductor cross-sectional area(mm²)Min To Max 4-6 | |||||||||||||||
Product Dimension:
