Name: Syntax UBM316 IP66 Waterproof Industrial Socket Outlet Box with 16A 3P 220V and Nickel Plated Brass Contacts
Brand: ZHEJIANG HANBEN ELECTRICAL CO., LTD.
SKU: UBM316
Availability: InStock

Detail Information

Plug / Socket:	Scoket (Wall Mounted Angled Type)	Current Rating (Ampere):	16A
Pole Format:	3P = 1P+N+E	Voltage Rating:	220V
IP Rating:	IP67	Mounting Type:	Cable Mount
Clock Position:	6h	Frequency (Hertz):	50-60 Hz
Identification Color:	Blue	Gender:	Female
Body Orientation:	Angled	Connection Technology:	Screw Terminal
Cable CSA (Cross-sectional Area):	2.5 Mm²	Material Of Plastic Housing:	PA6 = Polyamide 6 = Nylon 6
Material Of Metal Contacts:	Nickel Plated Brass	Maximum Operating Temperature:	+ 55°C
Minimum Operating Temperature:	- 25°C	International Standard:	EN/IEC 60309-2, DIN VDE 0623
Highlight:	wall mounted outdoor socket box , unswitched MCB protected sockets 16A , power supply box 16A

Product Description

Syntax UBM316 Single Phase Industrial Socket Outlet Box

Industrial-grade 16A/3P 220V socket outlet box with IP66 waterproof rating. Dimensions: 101×294×135mm.

Technical Specifications

Attribute	Value
Box Type	UBM Series Industrial Socket Outlet Box IP66
Color	Electric Grey
Dimensions	101×294×135mm
Incoming Main Switch	Direct connect through cable gland at top/bottom, protected by 1P 16A MCB
Outgoing Breaker 1	1×3P 16A 220V IP67 Panel Mounted Angled Socket, protected by main switch
Brand Components	Distribution Box by Syntax; Industrial Plugs & Sockets by PowerSyntax; Breakers by CHINT

Product Diagrams

Key Features & Benefits

Designed based on EN 61439-4 standards
Waterproof and shockproof design with IP65/IP66 ingress protection
Electric Grey color with customization options available
PC (Polycarbonate Resin) material construction
Operating temperature range: -20℃ to +75℃
MCB/RCD/RCBO protection options
No additional wiring required
Cable entry from top or bottom
Space for future modifications
Installation options: fixed or portable with lockable front cover
Individual segregation of outlets
IP67 industrial socket rating

Distribution Box Advantages

Quick assembly and dismantling
Safe and reliable connections
Reusable components
Suitable for indoor and outdoor use
Robust construction
Easy handling and system management
24-month warranty on all parts and manufacturing defects

Product Specifications

Pre-wired combination units feature one IEC/CEE socket on the front with ample connection space. Incoming cable access through top and bottom knockouts with supplied glands. Available with 1P 16A MCB and 3P 16A panel mounted angled socket IP67. Other configurations include 4P 16A, 5P 16A, 3P 32A, 4P 32A and 5P 32A sockets. Protection options include MCB, RCD, or RCBO based on requirements.

Material Performance

Constructed from PA6/PA66 Nylon material - a superior quality, toughened thermoplastic with excellent characteristics:

Abrasion resistant
Self-extinguishing
Heat and cold temperature resistant
Wear resistant
Excellent electrical insulation properties

Applications

Ideal for various industrial and commercial applications including:

Public Infrastructure: Urban rail transit, power stations, ports, airports, tunnels, construction sites
Manufacturing: Metal processing, power plants, steel works, automobile manufacturing
Communication: 4G/5G equipment, GPS, WiFi systems
Electronics & Food: Automated production lines
Entertainment: Concerts, stadiums, presentation venues
Civil: Hospitals, schools, banks, shopping malls
Electric Vehicles: Charging systems and distribution

Syntax by Zhejiang Hyper Electrical Supplies delivers high-quality portable power distribution solutions from 16A up to 630A. Our products feature cutting-edge technology, sophisticated design, and professional manufacturing for reliable electrical distribution in demanding environments.
